Item
項目 |
Symbol
符號 |
Content
詳細內容 |
Criterion
標準 |
|
|
過充保護
Over charge Protection |
VCU1 |
過充保護電壓
Over charge detection voltage |
4.25±0.025V |
|
|
tCU1 |
Over charge 1st detection delay time
1級過充電檢測延遲時間
|
1±0.3S |
||
|
VCL1 |
Over charge 1st release voltage |
4.10±0.05V |
||
|
Over discharge protection |
VDL |
Over discharge detection voltage
過放電檢測電壓 |
||
|
tDL |
Over discharge detection delay time |
1±0.3S |
||
|
VDU |
Over discharge release voltage
|
3.00±0.1V |
||
|
持續工作電流
Continue Current |
ICHG |
Continue charge current
持續充電電流 |
15A |
|
|
IDIS |
Continue discharge current
持續放電電流 |
15A |
||
|
過流保護
Over current protection |
IDIOV1 |
Over current detection current 1
過電流檢測電流 1 |
60A±8A |
|
|
tDIOV1 |
Overcurrent detection delay time 1
過電流保護延時1 |
12±3mS |
||
|
短路保護
Short current protection
|
ISHORT |
Short circuit detection current
短路保護檢測電流 |
350A |
|
|
tSHORT |
Short circuit delay time
短路保護延時 |
300-600us |
||
|
過流/短路保護 恢復
Over Short current release
|
/ |
Over current & short current release
過流及短路保護恢復 |
Load disconnection |
|
|
溫度保護Temperature protection |
NTC |
NTC溫度保護 |
充電最高溫度 |
50℃ |
|
放電最高溫度 |
70℃ |
|||
|
Internal resistance
保護板內阻 |
RCHG |
Resistance in charge 充電回路內阻 |
<30 mohm |
|
|
RDIS |
Resistance in discharge 充電回路內阻 |
<30 mohm |
||
|
Current consumption
靜態功耗 |
ISTB |
Current consume in normal operation
工作時電路內部消耗 |
<35uA |
|
